NA-FR5KD

5000W Max RMS 1-Channel Full Range Class D Amplifier

• RMS Power (@ 14.4V, < 1% T.H.D.):
  • 5000W @ 1Ω
  • 3500W @ 2Ω
  • 1900W @ 4Ω
• Frequency Response: 20 Hz – 20 kHz
• HPF Crossover Range: 15 Hz – 1 kHz
• LPF Crossover Range: 50 Hz – 15 kHz
• Bass Boost: 0 – 18 dB
• Bass Frequency: 35 Hz – 100 Hz
• Input Sensitivity: 0.2V – 10V
• Signal-to-Noise Ratio: > 90 dB
• Total Harmonic Distortion (T.H.D.): < 1.0%
• Remote Bass Knob: Included
• Dimensions: 15.5″ x 8.17″ x 2.5″
