NA-FR200X4D

Full-Range Class D 4-Channel Car Amplifier 1600 Watts Max

4Ch Full-Range Class D Amplifier
Maximum Output Power @ 14.4V (4-Ohm) 4X90W RMS
Maximum Output Power @ 14.4V (2-Ohm) 4X135W RMS
Maximum Output Power @ 14.4V (1-Ohm) 4X200W RMS
Maximum Output Power@14.4V (2-Ohm bridged) 2X400W RMS
Maximum Output Power@14.4V (4-Ohm bridged) 2X200W RMS
INPUT SENSITIVITY: 200MV
Signal-to-Noise Ratio: 100dB
Frequency Response: 10Hz-20KHz (-3dB)

Crossover:
H.P.F. (High Pass Filter) 15 to 6 KHz (-12dB/8) Variable
L.P.F. (Low Pass Filter) 50Hz to 6 KHz(-12dB/8) Variable
Bass Boost: 0-12dB (50Hz)
Thermal Management: Smart Cooling System
(Fan Powered by Temperature or
Audio Input Impedance: 56k Ohms
Protection System: Output Short/High/Low Supply
Voltage/Thermal Protection
Minimum Supply Voltage: 9V
Maximum Supply Voltage: 16V
