MICRO-1600X4D

1600W Max/ 800W RMS 4-Channel Class D Amp

• Max/RMS Power (@ 14.4V, < 1% T.H.D.):
  • 200W x 4CH MAX / 100W x 4CH RMS @ 4Ω
  • 300W x 4CH MAX / 150W x 4CH RMS @ 2Ω
  • 600W x 2CH MAX / 300W x 2CH RMS @ 4Ω (Bridged)
• Frequency Response: 20Hz – 20KHz
• Crossover Range: 40Hz – 400Hz
• Input Sensitivity: 0.2V – 10V
• Signal-to-Noise Ratio: > 90 dB
• Total Harmonic Distortion (T.H.D.): < 0.3%
• Dimensions: 227mm x 112mm x 43.6mm (or 8.94″ x 4.4″ x 1.72″)
